Description
Polycoat-Aquaseal™ 5000 WC/GC is a seamless and joint free waterproofing system created from a single component, water curable liquid applied, coal tar free, urethane/polyurea roofing and waterproofing membrane system for vertical and horizontal surfaces. The coating may be applied in the field from 30 to 250 mils (0.76-6.35 mm) in one application (when water catalyzed) while supplying simultaneous curing throughout the coating.
Material Use
Polycoat-Aquaseal 5000 WC/GC is a single-component, water-curable, coal tar-free urethane/polyurea liquid membrane. It is cold-applied and designed for waterproofing and roofing applications, formulated for both vertical and horizontal surfaces. It is available in three variants: horizontal (WC/GC-H), vertical (WC/GC-V), and spray-grade (WC/GC-SG).
This product is used for seamless, joint-free waterproofing and roofing. It is especially suited for complex substrate geometries and can be used to correct negative slope, fill ponding areas, and create a positive slope for drainage. It is intended for use in below-grade waterproofing, plaza decks, green roofs, tunnels, planters, between slabs, and more.
System Components
The system includes the base and top layers of Polycoat-Aquaseal 5000 WC/GC, optionally reinforced with approved fabric. The complete system may also include primers such as Polyprime 21 (recommended for concrete) and optionally Polyprime U or Polyprime 172 (used if re-coating beyond 48 hours). Reinforcing fabric is embedded between layers of membrane, and a protective board or geotextile composite is required after installation.
Applications
Typical applications include:
· Green roof waterproofing
· IRMA roofing
· Waterproofing under malls, plazas, promenade decks
· Bridges, tunnels, foundation walls, basements
· Planters, terrazzo/tile floors
· Modified cap sheets, between slabs
Application Details
· Mixing: Must be mixed with a mechanical mixer using a Jiffy-style paddle at low speed. Optional water catalyst (1 quart water per 5 gallons material) can be added to accelerate cure.
· Application Methods: Can be applied by brush, roller, squeegee, trowel, or spray.
· Thickness:
o Without water catalyst: max 30 mils per coat
o With water catalyst: up to 120 mils in one coat
o Full reinforced system:
§ 100 mils: 45 mils base + 45 mils top
§ 150 mils: 70 mils base + 70 mils top
· Coverage: Thickness determines coverage. Typically, ~60 mils in one water-catalyzed coat is recommended.
· Primer: Optional for plywood and CMU; Polyprime 21 recommended for concrete.
· Curing Time:
o 2–4 hours between coats (with water catalyst)
o 16–24 hours before protection board or backfilling
o Must re-prime with Polyprime U or 172 if over 48 hours between coats.
Special Notes
· Not UV stable – must be protected from UV exposure.
· Pot life after water mix is 20–30 minutes, depending on water ratio and temperature.
· Service temperature range: -25°F to 150°F (-31.7°C to 65°C).
· VOC Content: <50 g/L for WC/GC-H and V; <100 g/L for spray-grade.
· Substrates to avoid: on-grade slabs, unvented metal pans, lightweight concrete, swimming pools, magnesite.
· May be used over asphalt only if first coated with Aquaseal 5000 WC/GC.
· Surface must be dry, clean, and free of contaminants before application.
· Not to be diluted under any circumstances.
